Flexible solar panel 10w to 200w; Foldable solar panel 60w to 240w (2f&3f); Crystalline silicon solar panel 3w to 350w; OEM, OBM & ODM are availabel.
10 Years
| Ask Lasest Price | |
| Brand Name : | NSP, Motec |
| Model Number : | GS-M5inch |
| Price : | Get Latest Price |
| Delivery Time : | 1-2days |
| Payment Terms : | TT, Western Union, Money Gram |
| Supply Ability : | 3000000/month |
5inch mono-crystalline silicon solar cells in stock 2BB / 3BB for cheap sale
5Inch Solar Cell Specification:
-2BB monocrystalline solar cell
-Dimension: 125mm*125mm±0.5mm
-Thickness Wafer(Si): 200μm±20μm
-Cell: 240μm±40μm
-Front: 1.5mmSilver bus bars
-Dark blue/other silicon nitride antireflection coating
-Back 3.5mmSilver/Aluminum bus bars
-Full-surface aluminum BSF
5Inch Solar Cell Electrical Characteristics:
| No. | Efficiency(%) | Pmpp(W) | Umpp(V) | Impp(A) | Uoc(V) | Isc(A) |
| 10 | 19.40-19.50 | 3.01 | 0.54 | 5.61 | 0.64 | 5.93 |
| 9 | 19.30-19.40 | 2.99 | 0.54 | 5.58 | 0.64 | 5.92 |
| 8 | 19.20-19.30 | 2.97 | 0.54 | 5.55 | 0.64 | 5.92 |
| 7 | 19.10-19.20 | 2.96 | 0.53 | 5.54 | 0.64 | 5.9 |
| 6 | 19.00-19.10 | 2.94 | 0.53 | 5.51 | 0.64 | 5.89 |
| 5 | 18.90-19.00 | 2.93 | 0.53 | 5.5 | 0.63 | 5.87 |
| 4 | 18.80-18.90 | 2.91 | 0.53 | 5.47 | 0.63 | 5.86 |
| 3 | 18.70-18.80 | 2.9 | 0.53 | 5.46 | 0.63 | 5.85 |
| 2 | 18.60-18.70 | 2.88 | 0.53 | 5.43 | 0.63 | 5.84 |
| 1 | 18.40-18.60 | 2.85 | 0.53 | 5.4 | 0.63 | 5.84 |
*Date under standard testing conditions(STC): 1,000W/m2, AM1.5,
25oC
*All figures bear±3% of tolerance
*The measurement of cell is calibrated by Fraunhofer ISE.
5Inch Solar Cell Typical Temperature Coefficients:
*Voltage: -2.15 Mv /k
*Current: +4.4Mv/K
*Power: -0.46%/K
5Inch Solar Cell Package Detail:
-12 Boxes/CTN
-100 PCS /Box
-1200 PCS/CTN
-Gross Weight: 16.8 kg /CTN
-CTN size: 45*25*25mm
Payment terms:
T/T 30% in advance &the balance paid before delivery.
If samples, T/T 100% full payment in advance.
Cell Picture:
Fastest and cost-optimal Delivery
We always giving our clients the most economical and fastest deliery method. No matter the Air transportation / Ocean shipping / Internation express, our professional logistic team will ensure cargo transportation Safe and High efficiency.
|
|
